Universaladapter zur abwechselnden Aufzeichnung eines intravaskulären und eines Oberflächen-EKGs zur Positionierung zentralvenöser Katheter
Der Certodyn® Universaladapter ist ein Schaltgerät, das die EKG-geführte Katheterplatzierung auf der Grundlage von EKG-Signalen (P-Welle = intravaskuläre Position, erhöhter P-Spitze = intraatriale Position) mit einem EKG-Monitor ermöglicht.
Materialien: kein Körperkontakt
Verbindungsstücke: Buchse für Anschlusskabel für EKG-Elektrode Druckknopfadapter/ Clipadapter Elektrodenklemme
